What is the 1220s fully automatic insertion and extraction force testing machine?
In the field of industrial manufacturing and quality inspection, the insertion and extraction force testing machine is an important testing equipment used to evaluate the insertion and extraction performance and durability of connectors, plugs, sockets and other products. As a high-performance testing equipment, the 1220s fully automatic insertion and extraction force testing machine has attracted much attention in recent years. This article will introduce in detail the definition, functions, application scenarios and technical parameters of the 1220s fully automatic insertion and extraction force testing machine to help readers fully understand this equipment.
1. Definition of 1220s fully automatic insertion and extraction force testing machine
The 1220s fully automatic plug-in and pull-out force testing machine is an automated equipment specially used to test the plug-in and pull-out force of connectors. It simulates the plugging and unplugging action in actual use and measures the change in force value of the connector during the plugging and unplugging process to evaluate its performance and reliability. This equipment is widely used in electronics, automobiles, home appliances and other industries and is an important tool for product quality control.
2. Functions of 1220s fully automatic insertion and extraction force testing machine
The 1220s fully automatic insertion and extraction force testing machine has the following core functions:
| Function | Description |
|---|---|
| Automatic plug and unplug test | Simulate manual plugging and unplugging actions to achieve automated testing |
| Force measurement | Accurately measure the maximum force, minimum force and average force during plugging and unplugging |
| data logging | Automatically record test data and generate curves and reports |
| Durability test | Supports multiple plug-and-unplug cycles to evaluate connector durability |
| Abnormal alarm | When the test results exceed the set range, automatic alarm prompts |
3. Application scenarios of 1220s fully automatic insertion and extraction force testing machine
The 1220s fully automatic insertion and extraction force testing machine is suitable for a variety of industries and scenarios. The following are its main application areas:
| Industry | Application scenarios |
|---|---|
| Electronics industry | Test the plugging and unplugging performance of USB, HDMI, Type-C and other interfaces |
| Automotive industry | Evaluate the insertion and extraction force and durability of automotive connectors and wiring harnesses |
| Home appliance industry | Check the reliability of power plugs, sockets and other components |
| medical equipment | Test the insertion and extraction force and service life of medical connectors |
4. Technical parameters of 1220s fully automatic insertion and extraction force testing machine
The technical parameters of the 1220s fully automatic insertion and extraction force testing machine are an important reflection of its performance. The following are its main technical indicators:
| parameters | numerical value |
|---|---|
| Test force range | 0.1N~50N |
| Test speed | 1~500mm/min |
| Travel range | 0~100mm |
| Number of tests | 1~999,999 times |
| Data sampling rate | 1000Hz |
| Accuracy | ±0.5%FS |
5. Advantages of 1220s fully automatic insertion and extraction force testing machine
The 1220s fully automatic insertion and extraction force testing machine has the following advantages compared to traditional manual testing equipment:
1.High degree of automation: No manual intervention is required, reducing human errors and improving testing efficiency.
2.Accurate data: High-precision sensors and data acquisition systems ensure the accuracy of test results.
3.Easy to operate: Humanized operation interface, supports one-click startup and automatic report generation.
4.Multifunctional integration: Supports multiple test modes and data analysis functions to meet different needs.
6. Summary
The 1220s fully automatic insertion and extraction force testing machine is a high-performance, multi-functional testing equipment widely used in electronics, automobiles, home appliances and other industries. Its characteristics of automated testing, high-precision measurement and multi-functional integration make it an important tool for product quality control. Through the introduction of this article, I believe readers will have a more comprehensive understanding of the 1220s fully automatic insertion and extraction force testing machine.
